Cisco ASR 1001-X Router Hardware Installation Guide
OL-32376-02
Chapter 4 Cisco ASR 1001-X Router Installation
Connecting Cables
Note The two built-in 10 Gigabit Ethernet ports will only accept the SFP+ modules listed as supported in
Table 2-4. An SFP module check is run every time an SFP+ module is inserted into the two built-in 10
Gigabit Ethernet ports and only SFP+ modules that pass this check will be usable. SFP+ modules exist
for technologies other than Gigabit Ethernet and for products other than the two built-in 10 Gigabit
Ethernet ports.
Warning The built-in 1 GE SFP modules and two 10 GE SFP+ modules of the Cisco ASR 1001-X Router share the
same basic form factor and will fit in to each other’s port slots. If you accidentally install an SFP+
module into an SFP port or vice versa, the following error message is displayed:
Jun 23 12:07:51.273 EST: %TRANSCEIVER-6-INSERTED: SIP0/0: transceiver module
inserted in TenGigabitEthernet0/0/0
Jun 23 12:07:53.068 EST: %TRANSCEIVER-3-NOT_SUPPORTED: SIP0/0: Detected for
transceiver module in TenGigabitEthernet0/0/0, module disabled
Jun 23 12:08:09.273 EST: %TRANSCEIVER-6-INSERTED: SIP0/0: transceiver module
inserted in GigabitEthernet0/0/1
Jun 23 12:08:10.959 EST: %TRANSCEIVER-3-INIT_FAILURE: SIP0/0: Detected for
transceiver module in GigabitEthernet0/0/1, module disabled
The generic instructions for connecting the cables for the built-in Gigabit Ethernet ports installed in the
Cisco ASR 1000 Series Router are contained in the Cisco ASR 1000 Series Aggregation Services Routers
SIP and SPA Hardware Installation Guide at the following location:
http://www.cisco.com/c/en/us/td/docs/interfaces_modules/shared_port_adapters/install_upgrade/ASR1
000/asr_sip_spa_hw.html
Connecting the Shared Port Adapter Cables
The instructions for connecting the cables for the shared port adapter installed in the Cisco ASR 1001-X
Router are contained in the Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Hardware
Installation Guide at:
http://www.cisco.com/c/en/us/td/docs/interfaces_modules/shared_port_adapters/install_upgrade/ASR1
000/asr_sip_spa_hw.html

Cisco ASR 1001-X Specifications

General

Product color	Gray
Rack capacity	1U
Rack mounting	Yes
Networking standards	-
Ethernet LAN (RJ-45) ports	6
Installed SFP modules quantity	2
Flash memory	1024 MB
Internal memory	8192 MB
Processor cores	4
AC input voltage	85 - 264 V
Power source type	AC
Power consumption (typical)	250 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Security algorithms	AES

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	10590 g
