Cisco ASR 9000 Series Hardware Installation Guide

Table 13: 1-Port OC48-POS/RPR SPA LEDs
MeaningStateColorLED Label
Port is not in wrap mode.OffOffWRAP
Port is in wrap mode somewhere on the ring.OnGreen
Port is in wrap mode locally.OnAmber
Port is not in pass-through mode.
OffOffPASSTHRU
Port is in pass-through mode.OnAmber
Mate port is not synchronized.
OffOffMATESYNC
Mate port is synchronized.OnGreen
Port is not enabled by software.
OffOffC/A
Port is enabled by software.OnGreen
Port is enabled by software, and there is at least one
alarm.
OnAmber
Port is not enabled by software.
OffOffA/L
Port is enabled by software, loopback is off.OnGreen
Port is enabled by software, loopback is on.OnAmber
Port is not enabled by software.
OffOffCARRIER
Port is enabled by software, and there is a valid
SONET signal without alarms.
OnGreen
Port is enabled by software, and there is at least one
alarm (LOS, LOF, RDI, and so on).
OnAmber
SRP mode mismatch alarm is indicated.Blinking
Port is not enabled by software.Off
OffACTIVE
Port is enabled by software, and loopback is off.OnGreen
Port is enabled by software, and loopback is on.OnAmber
SPA power off.
OffOffSTATUS
SPA is ready and operational.OnGreen
SPA power is on and good, and the SPA is being
configured.
OnAmber
Cisco ASR 9000 Series Aggregation Services Router SIP and SPA Hardware Installation Guide
18
Overview: Cisco ASR 9000 Series Router Shared Port Adapters
1-Port OC48-POS/RPR SPA LEDs
