Cisco ASR 9000 Series Hardware Installation Guide

Figure 20: SPA Mate Cables
Short length RPR mate cable for single port RPR
SPAs (CAB-RPR-OC192-S)
2Long length RPR mate cable for single port RPR
SPAs (CBL-RPR-OC192-L)
1
The RPR mate cable is necessary only when the SPA is to be used in RPR mode. It is not needed in POS
mode. Support for the RPR feature is dependent on the platform software-release feature content. Verify
support for the RPR feature support using SPA datasheets or by contacting your Cisco representative.
Note
2-Port and 4-Port Clear Channel T3/E3 SPA Overview
The following sections describe the 2-Port and 4-Port Clear Channel T3/E3 SPA:
2-Port and 4-Port Clear Channel T3/E3 SPA LEDs
The 2-Port and 4-Port Clear Channel T3/E3 SPA has three types of LEDs: two LEDs for each port on the
SPA, and one STATUS LED, as shown in the following figure.
Cisco ASR 9000 Series Aggregation Services Router SIP and SPA Hardware Installation Guide
29
Overview: Cisco ASR 9000 Series Router Shared Port Adapters
2-Port and 4-Port Clear Channel T3/E3 SPA Overview
