STATUS LED5RX (Receive) connector2
C/A (Carrier/Alarm) LED3
The 2-Port Channelized T3/E3 ATM CEoP SPA LEDs are described in the following table.
Table 37: 2-Port Channelized T3/E3 ATM CEoP SPA LEDs
MeaningStateColorLED Label
Port is not enabled by software.OffOffC/A
Port is enabled by software.OnGreen
Port is enabled by software and there is at least one alarm.OnAmber
Port is not enabled by software.OffOffA/L
Port is enabled by software, loopback is off.OnGreen
Port is enabled by software, loopback is on.OnAmber
SPA power is off.OffOffSTATUS
SPA power is on and the SPA is being configured.OnAmber
SPA is ready and operational.OnGreen
2-Port Channelized T3/E3 ATM CEoP SPA Interface Specifications
The framer processes the incoming and outgoing T3 (C-Bit, m13/m23, and unframe) and E3 (g751) frames.
The framer operates at T3 or E3 line rates (44.736 or 34.368 Mbps), depending on the mode in which it is
configured.
The T3 or E3 data is encapsulated and sent across the MPLS network over user-configurable pseudowires.
In the ATM, the data is encapsulated into ATM cells and transported across the network
The T3/E3 SPA interface is compliant with ANSI and Telco standards. The interface also provides support
for Management Information Base (MIB) RFC 2495, RFC 2496, and T1.231.
2-Port Channelized T3/E3 ATM CEoP SPA Cables and Connectors
The interface connectors on the 2-Port Channelized T3/E3 ATM CEoP SPA are 75-ohm coaxial DIN 1.0/2.3
types, with one connector and cable for transmit (TX) and one for receive (RX).
The following cables can be used with the 2-Port Channelized T3/E3 ATM CEoP SPA. The cables have BNC
connectors on one end and DIN 1.0/2.3 connectors on the other end. If similar SPAs are connected back-to-back,
both ends of the cable are DIN 1.0/2.3.
The cables specifications that can be used for the 2-Port Channelized T3/E3 ATM CEoP SPA are:
• CAB-T3E3-RF-BNC-M (T3 or E3 Cable, 1.0/2.3 RF to mini BNC-Male, 10 feet)
• CAB-T3E3-RF-BNC-F (T3 or E3 Cable, 1.0/2.3 RF to mini BNC-Female, 10 feet)
• CAB-T3E3-RF-OPEN (T3 or E3 Cable, 1.0/2.3 RF to BNC-Open end, 10 feet)
Cisco ASR 9000 Series Aggregation Services Router SIP and SPA Hardware Installation Guide
60
Overview: Cisco ASR 9000 Series Router Shared Port Adapters
2-Port Channelized T3/E3 ATM CEoP SPA Interface Specifications
