Cisco ASR 9000 Series Hardware Installation Guide

MeaningStateColorLED Label
Port is enabled by software, and there is at least one alarm.OnAmber
Port is not enabled by software.OffOffA/L
Port is enabled by software, and loopback is off.OnGreen
Port is enabled by software, and loopback is on.OnAmber
SPA power is off.OffOffSTATUS
SPA power is on and good, and SPA is being configured.OnAmber
SPA is ready and operational.OnGreen
1-Port Clear Channel OC-12 ATM SPA Interface Specifications
The physical layer interface for the 1-Port Clear Channel OC-12 ATM SPA is Optical Carrier-12 (OC-12),
and the 1-Port Clear Channel OC-12 ATM SPA is designed to comply with ATM specifications. The 1-Port
Clear Channel OC-12 ATM SPA provides one 622.08 Mbps OC-12 network interface for all supported
platforms.
The single SPA port accepts an SFP module with a duplex LC-type receptacle that allows connection to
single-mode or multimode optical fiber.
1-Port Clear Channel OC-12 ATM SPA Cables and Connectors
The 1-Port Clear Channel OC-12 ATM SPA uses a small form-factor pluggable (SFP) optical transceiver
module installed in each port for SONET and SDH single-mode and multimode optical fiber connection (see
the below figure).
The 1-Port Clear Channel OC-12 ATM SPA supports the following types of optical transceiver modules:
Multimode (MM) SFP module—SFP-OC12-MM
Short-reach (SR) SFP module—SFP-OC12-SR
Intermediate-reach (IR) SFP module (15 km)—SFP-OC12-IR1
Long-reach (LR) SFP module (40 km)—SFP-OC12-LR1
Long-reach (LR) SFP module (80 km)—SFP-OC12-LR2
The SR, IR, and LR1 transceivers provide a full-duplex 622.08-Mbps, laser-based SONET/SDH- compliant
interface with an average wavelength of 1310 nm. The LR2 transceivers provide a full-duplex, 622.08-Mbps,
laser-based SONET/SDH-compliant interface with an average wavelength of 1530 nm. The multimode
transceiver provides a full-duplex, 622.08-Mbps, LED-based SONET/SDH-compliant interface with an
average wavelength of 1325 nm.
