Cisco ASR 9010

Figure 58: NEBS Bonding and Grounding Point on the Cisco ASR 9906 Router Chassis
NEBS grounding point on
left side of chassis
2NEBS grounding point on
rear of the chassis
1
Figure 59: NEBS Bonding and Grounding Point on the Cisco ASR 9912 Router
NEBS grounding point near bottom, rear, right side
of the chassis
1
Cisco ASR 9000 Series Aggregation Services Router Hardware Installation Guide
46
Preparing for Installation
NEBS Supplemental Unit Bonding and Grounding Guidelines
