Chapter 1 Product Overview
Front Panel
Figure 1-3 Catalyst 3650-24PDM Switches Front Panel
1 Mode button 4 USB Type A storage port
2 Status LEDs 5 10/100/1000 PoE+ Ethernet ports
3 USB mini-Type B (console) port 6 Uplink ports
1 Mode button 4 USB Type A storage port
2 Status LEDs 5 10/100/1000 PoE+ Ethernet ports
3 USB mini-Type B (console) port 6 Uplink ports
