Catalyst 3650 Switch Hardware Installation Guide

OL-29734-01

Chapter 1 Product Overview

Rear Panel

Figure 1-15 Catalyst 3650-8X24UQ/PD and 3650-12X48FD/UQ/UR/UZ Switches Rear Panel

1 Ground connector 6 Data stack ports

2 BEACON LED 7 AC OK (input) status LED
