Cisco Catalyst 3650 Series

4-3
Catalyst 3650 Switch Hardware Installation Guide
OL-29734-01
Chapter 4 Power Supply Installation
Power Supply Module Overview
Figure 4-1 1100-W AC Power Supply
Figure 4-2 715-W AC Power Supply Module
1 1100-W AC power supply module 5 Release latch
2 AC OK LED 6 Power cord retainer
3 PS OK LED 7 Keying feature
4 AC power cord connector
AC OK
PWR-C1-1100WAC
PS OK
334375
1
7
6
2
3
4
5
1 715-W AC power supply module 5 Release latch
2 AC OK LED 6 Power cord retainer
3 PS OK LED 7 Keying feature
4 AC power cord connector
AC OK
PWR-C1-715WAC
PS OK
334376
1
6
2
3
4
5
7
