Cisco Catalyst 4500e Series User Manual

A-9
Catalyst 4500 E-Series Switches Installation Guide
OL-13972-01
Appendix A Specifications
Catalyst 4500 Power Supplies
Input power
Current draw At –40.5 V (min voltage)
Current draw at –72 V (max voltage)
Max heat dissipation at 1866 W
1866 W (Data only)
46 A
25.9 A
5760 BTUs
179 A max @ 48 VDC
Maximum KVA rating 1.87 (data)
9.15 (data and voice)
Power supply output (DC supply) Data: 12 V @120 A, 3.3 V @ 10 A
Inline devices: 140 A total maximum (35 A maximum each
per 5 channels) @–48 to 60
VDC input
1367 W+ 40 W redundant mode (Data)
2267 W maximum in combined mode (Data)
7500 W maximum each in redundant mode (PoE)
7280 W maximum in combined mode (PoE)
DC input terminal block Accepts FCI p/n YAV25L2TC14FX90 or equivalent,
barrel-type lug terminals with 90-degree angle, two- hole
tongue, which accommodates 1/0 AWG size copper wire. The
connector tongue width is 0.82 in, the stud hole spacing is 5/8 in,
and the hole size is 1/4 in.
Output holdup time 4 ms
Max heat dissipation 1591 BTUs/hr (data)
2905 BTUs/hr (data and voice)
Catalyst 4503-Specific Power Usage (data
only)
Maximum draw 475 W
Maximum input 633 W
Current draw at –40.5 V (min voltage)
Current draw at –72 V (max voltage)
15.6 A
8.8 A
Max heat dissipation at 633 W 2160 BTUs
Catalyst 4506-Specific Power Usage (data
only)
Maximum draw (data only) 850 W
Maximum input 1133 W
Current draw at –40.5 V (min voltage)
Current draw at –72 V (max voltage)
28 A
15.8 A
Max heat dissipation at 1133 W 3515 BTUs
Catalyst 4507R-E Specific Power Usage
(data only)
Maximum draw (data only) 1080 W
Max input is 1080 W / 0.75 = 1440 W
Table A-8 1400 W DC-Input Power Supply Specifications (continued)
Item Specification

Cisco Catalyst 4500e Series Specifications

General

Series	Catalyst 4500E Series
Stackable	No
Chassis Options	3-slot, 6-slot, 7-slot, 10-slot
Power Supply Options	AC, DC
Redundancy	Power supply redundancy, supervisor engine redundancy (1+1)
Layer Support	Layer 2
Virtualization	Yes (Virtual Switching System - VSS)
Form Factor	Modular
Ports	Gigabit Ethernet, 10 Gigabit Ethernet, 40 Gigabit Ethernet, and 100 Gigabit Ethernet options depending on the line cards
Jumbo Frame Support	Yes
Features	Flexible NetFlow, TrustSec
Maximum Port Density	Up to 384 ports per chassis
Operating System	Cisco IOS XE
Management	CLI, SNMP, Cisco Prime Infrastructure, Cisco DNA Center
Security Features	802.1X
VLAN Support	Up to 4096 VLANs
QoS Support	Yes
Supervisor Engine Options	Sup8-E
