Appendix A Specifications
Catalyst 4500 Power Supplies
Current draw at –40.5 V (min voltage)
Current draw at –72 V (max voltage)
35.6 A
20 A
Max heat dissipation 1440 W 4910 BTUs
Ta b l e A-9 1400 W DC Triple-Input Power Supply Specifications
Item Specification
Minimum software requirement Cisco IOS Release 12.2(25)EW
Power over Ethernet Not supported
DC-input voltage Domestic and international: –48 to –60 VDC
DC-input current 42.5 A maximum @ –48 VDC input
Input 1: 12.5 A at –48 to –60 VDC
Input 2: 15 A at –48 to –60 VDC
Input 3: 15 A at –48 to –60 VDC
Input power
Current draw At –40.5 V (min voltage)
Current draw at –72 V (max voltage)
Max heat dissipation at 1400 W
1772 W @ 1400 W output power
42.5 A
25 A
1269 BTUs
Maximum KVA rating 1.77 at 1400 W load
Power supply output (DC supply) 12 V@ 8 A minimum, 115.3 A maximum
3.3 V @ 1.2 A minimum, 12.5 A maximum
1360 W+ 40 W redundant mode
2450 W maximum in combined mode
DC input terminal block Model: Cooper Bussmann Magnum. Accepts terminals with
flat angle, one hole tongue, which accommodates 10 to 12
AWG size copper wire. The connector the barrier spacing is
0.378 in (9.6 mm), and the screw size is 8-32.
Output holdup time 8 ms
Max heat dissipation 1269 BTUs/hr
Table A-8 1400 W DC-Input Power Supply Specifications (continued)
Item Specification

Cisco Catalyst 4500e Series Specifications

General

Series	Catalyst 4500E Series
Stackable	No
Chassis Options	3-slot, 6-slot, 7-slot, 10-slot
Power Supply Options	AC, DC
Redundancy	Power supply redundancy, supervisor engine redundancy (1+1)
Layer Support	Layer 2
Virtualization	Yes (Virtual Switching System - VSS)
Form Factor	Modular
Ports	Gigabit Ethernet, 10 Gigabit Ethernet, 40 Gigabit Ethernet, and 100 Gigabit Ethernet options depending on the line cards
Jumbo Frame Support	Yes
Features	Flexible NetFlow, TrustSec
Maximum Port Density	Up to 384 ports per chassis
Operating System	Cisco IOS XE
Management	CLI, SNMP, Cisco Prime Infrastructure, Cisco DNA Center
Security Features	802.1X
VLAN Support	Up to 4096 VLANs
QoS Support	Yes
Supervisor Engine Options	Sup8-E
