Cisco Catalyst 4500e Series User Manual

A-11
Catalyst 4500 E-Series Switches Installation Guide
OL-13972-01
Appendix A Specifications
Catalyst 4500 Power Supplies
Catalyst 4503-E Specific Power Usage
(data only)
Two modules minimum required @ –40.5 VDC input
One 15A module minimum required @ –44 VDC input
Maximum draw 475 W
Maximum input 609 W total / # of modules = W per module
Current draw at –40.5 V (min voltage)
Current draw at –72 V (max voltage)
15 A total / # of modules = A per module
8.5 A total / # of modules = A per module
Max heat dissipation at 609 W 2078 BTUs
Catalyst 4506-E Specific Power Usage
(data only)
Two modules minimum required @ –44 VDC input
Three modules minimum required @ –40.5 VDC input
Maximum draw (data only) 850 W
Maximum input 1076 W total / # of modules = W per module
Current draw at –40.5 V (min voltage)
Current draw at –72 V (max voltage)
26.6 A total / # of modules = A per module
15 A total / # of modules = A per module
Max heat dissipation at 1076 W 3671 BTUs
Catalyst 4507R-Specific Power Usage
(data only)
Three modules minimum required
Maximum draw (data only) 1080 W
Max input is 1080 W 1367 W total / # of modules = W per module
Current draw at –40.5 V (min voltage)
Current draw at –72 V (max voltage)
33.75 A total / # of modules = A per module
19 A total / # of modules = A per module
Max heat dissipation 1367 W 4665 BTUs
Ta b l e A-10 Input Modes
Input
Mode
Input
Number
Input Configuration
Maximum Total Output
Power
1 1 1 x 12.5 A 386 W @ –40.5 VDC
412 W @ –44.0 VDC
2 2 OR 3 1 x 15 A 466 W @ –40.5 VDC
495 W @ –44.0 VDC
3 1, 2 OR 3 1 x 12.5 A and
1 x 15 A
845 W @ –40.5 VDC
908 W @ –44.0 VDC
4 2, 3 2 x 15 A 914 W @ –40.5 VDC
990 W @ –44.0 VDC
5 1, 2, 3 1 x 12.5 A and
2 x 15 A
1294 W @ –40.5 VDC
1400 W @ –44.0 VDC
Table A-9 1400 W DC Triple-Input Power Supply Specifications (continued)
Item Specification

Cisco Catalyst 4500e Series Specifications

General

Series	Catalyst 4500E Series
Stackable	No
Chassis Options	3-slot, 6-slot, 7-slot, 10-slot
Power Supply Options	AC, DC
Redundancy	Power supply redundancy, supervisor engine redundancy (1+1)
Layer Support	Layer 2
Virtualization	Yes (Virtual Switching System - VSS)
Form Factor	Modular
Ports	Gigabit Ethernet, 10 Gigabit Ethernet, 40 Gigabit Ethernet, and 100 Gigabit Ethernet options depending on the line cards
Jumbo Frame Support	Yes
Features	Flexible NetFlow, TrustSec
Maximum Port Density	Up to 384 ports per chassis
Operating System	Cisco IOS XE
Management	CLI, SNMP, Cisco Prime Infrastructure, Cisco DNA Center
Security Features	802.1X
VLAN Support	Up to 4096 VLANs
QoS Support	Yes
Supervisor Engine Options	Sup8-E
