A-12
Catalyst 4500 E-Series Switches Installation Guide
OL-13972-01
Appendix A Specifications
Catalyst 4500 Power Supplies
Ta b l e A-11 Allowable Power with Two 1400 W DC Triple-Input Power Supplies in Combined
Mode
PS1/PS2 1 2 or 3
1 and
(2 or 3) 2 and 3 1 and 2 and 3
1 824 W 907 W 1320 W 1400 W 1700 W
2 or 3 907 W 990 W 1400 W 1450 W 1750 W
1 and (2 or 3) 1320 W 1400 W 1700 W 1750 W 1900 W
2 and 3 1400 W 1450 W 1750 W 1820 W 2130 W
1 and 2 and 3 1700 W 1750 W 1900 W 2130 W 2450 W
Ta b l e A-12 2800 W AC-Input Power Supply Specifications
Item Specification
Minimum software requirement Cisco IOS Release 12.1(13)EW
Power over Ethernet Supported, up to 1400 W
(240 Cisco phones in combined mode)
AC-input type Autoranging input with power factor corrector
AC-input voltage 200 to 240 VAC (±10% for full range)
AC-input current 16 A maximum at 200 VAC
AC-input frequency 50/60 Hz (nominal) (±3% for full range)
Maximum KVA rating 3.52 KVA
Power supply output 2800 W maximum
12 V @113.3 A, 3.3 V @12.1 A (Data)
–50 V @28 A (PoE)
1360 W+ 40 W redundant mode (Data)
2473 W maximum in combined mode (Data)
1400 W maximum each in redundant mode (PoE)
2333 W maximum in combined mode (PoE)
Max heat dissipation 2387 BTUs/hr.
Output holdup time 20 ms minimum
Ta b l e A-13 4200 W AC-Input Power Supply Specifications
Item Specification
Minimum software requirement Cisco IOS Release 12.2(25)EWA
Power over Ethernet Supported, up to 4200 W
AC-input type Autoranging input with power factor corrector
AC-input voltage 100 to 240 VAC (±10% for full range)
AC-input current 16 A maximum at 200 VAC
AC-input frequency 50/60 Hz (nominal) (±3% for full range)

Cisco Catalyst 4500e Series Specifications

General

Series	Catalyst 4500E Series
Stackable	No
Chassis Options	3-slot, 6-slot, 7-slot, 10-slot
Power Supply Options	AC, DC
Redundancy	Power supply redundancy, supervisor engine redundancy (1+1)
Layer Support	Layer 2
Virtualization	Yes (Virtual Switching System - VSS)
Form Factor	Modular
Ports	Gigabit Ethernet, 10 Gigabit Ethernet, 40 Gigabit Ethernet, and 100 Gigabit Ethernet options depending on the line cards
Jumbo Frame Support	Yes
Features	Flexible NetFlow, TrustSec
Maximum Port Density	Up to 384 ports per chassis
Operating System	Cisco IOS XE
Management	CLI, SNMP, Cisco Prime Infrastructure, Cisco DNA Center
Security Features	802.1X
VLAN Support	Up to 4096 VLANs
QoS Support	Yes
Supervisor Engine Options	Sup8-E
