Catalyst 6500 Series Switch and Cisco 7600 Series Router Firewall Services Module Configuration Guide
OL-6392-01
Quick Start Steps
The following sections describe the minimum configuration required for the Firewall Services Module
(FWSM) in routed mode or transparent mode:
• Routed Firewall Configuration Steps, page xxiii
• Transparent Firewall Configuration Steps, page xxv
Routed Firewall Configuration Steps
Follow these steps to configure the FWSM in routed mode:
Task Description
Step 1
Assigning VLANs to the Firewall Services Module, page 2-2 On the switch, you need to assign VLANs to the
FWSM so the FWSM can send and receive traffic on
the switch.
Step 2
(Might be required) Adding Switched Virtual Interfaces to
the MSFC, page 2-5
If you want the Multilayer Switch Feature Card
(MSFC) to route between VLANs that are assigned to
the FWSM, complete this procedure.
Step 3
Sessioning and Logging into the Firewall Services Module,
page 3-1
From the switch CLI, you can session into the FWSM
to access the FWSM CLI.
Step 4
(Might be required; multiple context mode only) Enabling or
Disabling Multiple Context Mode, page 5-10
If you want to use multiple context mode and your
FWSM is not already configured for it, or if you want
to change back to single mode, follow this procedure.
Step 5
(Multiple context mode only) Configuring a Security
Context, page 5-19
Add a security context.
Step 6
(Multiple context mode only) Changing Between Contexts
and the System Execution Space, page 5-22
You must configure some settings in the system
execution space, and some settings within the
context, so you need to know how to switch between
contexts and the system execution space.
Step 7
Setting the Name and Security Level, page 6-7 For each VLAN interface, you must set a name (such
as inside or outside) and a security level.
Step 8
Assigning IP Addresses to Interfaces for a Routed Firewall,
page 8-2
Assign an IP address to each interface.
Step 9
Configuring the Default Route, page 8-2 Create a default route to an upstream router.
