DescriptionFeature
For Cisco Catalyst 6807-XL switches:
•
Fabric channel 0 : Ports 1 to 8
•
Fabric channel 1: Ports 9 to 15
•
Fabric channel 2 : Ports 17 to 24
•
Fabric channel 3 : Ports 25 to 32
For Cisco Catalyst 6500-E series switches:
•
Fabric channel 0 : Ports 1 to 16
•
Fabric channel 1: Ports 17 to 32
Fabric connection
In a Cisco Catalyst 6807-XL chassis—160 GB per second
In a Cisco Catalyst 6500-E series chassis—80 GB per second
Fabric channel speed
PoE—Not supported
Distributed forwarding— The C6800-32P10G module ships with
a factory-installed DFC4-E and the C6800-32P10G-XL module
ships with a factory-installed DFC4-EXL daughter card. The
modules are not field upgradable.
Module upgrade availability
These Ethernet modules support 10G SFP+ modules and 1G SFP
modules. For SFP transceivers currently supported, refer to the
Cisco Transceiver Modules compatibility matrices at:
Compatibility Information
Pluggable transceivers support
Supported with GLC-T (1G Copper SFP) transceiversTDR support
• The DOM-supported 1G transceivers are—GLC-BX-U,
GLC-BX-D, GLC-SX-MMD, GLC-EX-SMD,
GLC-LH-SMD, GLC-ZX-SMD, SFP-DWDM.
•
The DOM-supported 10G Fiber SFP/SFP+ transceivers are
listed at Cisco Digital Optical Monitoring Compatibility
Matrix.
Digital Optical Monitoring (DOM)
support
Related Topics
Installing an Ethernet Switching Module, on page 25
C6800-32P10G and C6800-32P10G-XL Module Specifications, on page 43
Ethernet Module LEDs, on page 45
Catalyst 6800 Ethernet Module Installation Guide
16
Ethernet Switching Modules Overview
C6800-32P10G and C6800-32P10G-XL Ethernet Modules
