Release latch51100 W AC power supply module1
Power cord retainer6AC OK LED2
Keying feature7PS OK LED3
--AC power cord connector4
Figure 47: 1900 W AC Platinum Certified Power Supply
AC power cord connector51900 W AC power supply module1
Release latch6Keying feature2
Power cord retainer7AC OK LED3
PS OK LED4
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
84
Installing a Power Supply
Power Supply Modules Overview
