Antenna NameConnectorAntenna Gain (dBi)PID
Cisco Aironet 5 GHz 8 dBi
Omnidirectional Dipole Antenna
N male87—AIR-ANT5180V-N=
Cisco Aironet 2.4/5 GHz 8 dBi
4-Element Dual-Polarized Patch
Antenna, Self-Identifying
N female
(x4)
9.6 (V),
7.8 (H)
—9.1 (V),
7.1 (H)
AIR-ANT2588P4M-NS=
Cisco Aironet 2.4 GHz 13 dBi
Dual-Port Dual-Polarized Directional
Panel Antenna
N male (x2)——13AIR-ANT2413P2M-N=
Cisco Aironet 5 GHz 13 dBi
Dual-Port Dual-Polarized Directional
Panel Antenna
N male (x2)13——AIR-ANT5114P2M-N=
Cisco Aironet Four-Port Dual-Band
Polarization-Diverse Directional
Panel Antenna
N female
(x4)
13—13AIR-ANT2513P4M-N=
Cisco Aironet Four-Port Dual-Band
Polarization-Diverse Directional
Panel Antenna, Self-Identifying
N female
(x4)
13—13AIR-ANT2513P4M-NS=
For installation instructions and detailed information on any of these antennas, refer to the antenna data sheet
on Cisco.com, or see the antenna guides at:
• Cisco Industrial Routers and Industrial Wireless Access Points Antenna Guide
• http://www.cisco.com/c/en/us/support/wireless/aironet-antennas-accessories/
products-installation-guides-list.html
Follow all safety precautions when installing the antennas. For information on safety, see Safety Precautions
when Installing Antennas, on page 59.
Supported URWB Antennas
Table 5: Supported URWB Antennas
Antenna NameConnectorAntenna Gain (dBi)PID
5 GHz4.9
GHz
2.4
GHz
5 GHz Omnidirectional
Multi-Polarized Antenna
N female33—IW-ANT-OMM-53-N=
5 GHz Dual-Port Dual-Slant +/-45
Degree Polarized Directional Panel
Antenna
N female
(x2)
9——IW-ANT-PNL-59-N=
5 GHz Directional Shark Antenna,
Dual-Slant +/-45 Degree Polarized
QMA
female (x2)
1414—IW-ANT-SKS-514-Q=
