Do not connect omnidirectional antennas directly to both ports 1 - 4 and ports 5 - 8. To avoid interference
between the 5 GHz radios, use coaxial cables and mount one set of antennas at least 3 ft. (1 m) vertically away
from the antennas attached directly to the chassis. Omnidirectional antennas may be connected to either ports
1 - 4 or 5 - 8, but not to any combination of both 5 GHz radios' antenna ports simultaneously.
If you connect directional antennas to both 5 GHz radios, space them at least 10 ft. (3 m) apart vertically, or
at least 5 ft. (1.5 m) apart horizontally with their main beams aimed at least 90 degrees apart.
Note
Supported Wi-Fi Antennas
The following table shows the external Wi-Fi antennas supported by the IW9167EH access point.
Table 4: Supported Wi-Fi Antennas
Antenna NameConnectorAntenna Gain (dBi)PID
5 GHz4.9
GHz
2.4
GHz
2.4/5 GHz Tri-Band Omnidirectional
Dipole Antenna, Vertically Polarized,
Self-Identifying
N male774IW-ANT-OMV-2567-N=
2.4/5 GHz Tri-Band Omnidirectional
Dipole Antenna, Horizontally
Polarized, Self-Identifying
N male774IW-ANT-OMH-2567-N=
Cisco Aironet Dual-Band
Omnidirectional Dipole Antenna
(White)
N male7—4AIR-ANT2547V-N=
Cisco Aironet Dual-Band
Omnidirectional Dipole Antenna
(Gray)
N male7—4AIR-ANT2547VG-N=
Cisco Aironet Dual-Band
Omnidirectional Dipole Antenna
(Gray), Self-Identifying
N male7—4AIR-ANT2547VG-NS=
Cisco Aironet Dual-Band
Omnidirectional Dipole Antenna
(Gray)
N male8—6AIR-ANT2568VG-N=
Cisco Aironet Dual-Band
Omnidirectional Dipole Antenna
(Gray), Self-Identifying
N male8—6AIR-ANT2568VG-NS=
Cisco Aironet 2.4 GHz 8 dBi
Omnidirectional Dipole Antenna
N male——8AIR-ANT2480V-N=
