PurposeCommand or Action
avg-rate 3 sample-interval 10 penalty 120
upstream enforce
(Optional) Specifies the period for which an
enforced QoS profile should be in effect for
penalty-period minutes [time-of-day
{hour|hour:minutes}] [monitoring-on]
Step 8
subscribers who violate their registered QoS
profiles.
Example:
Router(enforce-rule)# penalty-period 10
(Optional) Activates the enforce-rule and begins
subscriber traffic management.
enabled
Example:
Router(enforce-rule)# enabled
Step 9
Exits enforce-rule configuration mode and returns
to privileged EXEC mode.
end
Example:
Router(enforce-rule)# end
Step 10
Examples
This section provides command-line interface (CLI) examples, including the help feature for some of the
enforce-rule commands.
Example: Legacy Monitoring Configuration
The following example shows a sample configuration of an enforce-rule for legacy monitoring:
Router(config)# cable qos enforce-rule test
Router(enforce-rule)# monitoring-basics ?
legacy Enable legacy (same average rate for all day) monitoring
peak-offpeak Enable peak-offpeak monitoring
Router(enforce-rule)# monitoring-basics legacy ?
docsis10 Enforce-rule will map to docsis 1.0 modems
docsis11 Enforce-rule will map to docsis 1.1 modems
Router(enforce-rule)# monitoring-basics legacy docsis11
Router(enforce-rule)# service-class ?
enforced Enforced service class
registered Registered service class
Router(enforce-rule)# service-class registered ?
WORD Registered service class name
Router(enforce-rule)# service-class registered BEUS
Router(enforce-rule)# service-class enforced test
Router(enforce-rule)# duration ?
<10-10080> Duration in minutes
Router(enforce-rule)# duration 10 ?
avg-rate Average rate for the duration in kbits/sec
Router(enforce-rule)# duration 10 avg-rate ?
<1-4294967> average rate in kbits/sec
Router(enforce-rule)# duration 10 avg-rate 2 ?
sample-interval Rate of sampling in Minutes
Router(enforce-rule)# duration 10 avg-rate 2 sample-interval ?
<1-30> Sampling rate in Minutes
