Cisco CRS Series - Configuring an RPF Topology in PIM; Information about Multitopology Routing

◦
Open Shortest Path First (OSPF)
◦
Intermediate System-to-Intermediate System (IS-IS)
◦
Multiprotocol Border Gateway Protocol (MBGP)
Although both multicast and unicast keywords are available when using the address-family {ipv4 |
ipv6} command in routing policy language (RPL), only topologies under multicast SAFI can be configured
globally.
Note
Information About Multitopology Routing
Configuring multitopology networks requires the following tasks:
• “Configuring a Global Topology and Associating It with an Interface” (required)
For information, see Cisco IOS XR Routing Configuration Guide for the Cisco CRS Router.
• “Enabling an IS-IS Topology” (required)
For information, see Cisco IOS XR Routing Configuration Guide for the Cisco CRS Router.
• “Placing an Interface in a Topology in IS-IS” (required)
For information, see Cisco IOS XR Routing Configuration Guide for the Cisco CRS Router.
• “Configuring a Routing Policy” (required)
For information, see Cisco IOS XR Routing Configuration Guide for the Cisco CRS Router.
For an example of multitopology routing, see Configuring Multitopology Routing: Example, on page 159.
Configuring an RPF Topology in PIM
SUMMARY STEPS
1.
configure
2.
router pim address-family {ipv4 | ipv6}
3.
rpf topology route-policy policy-name
4.
exit
5.
multicast-routing address-family {ipv4 | ipv6}
6.
interface all enable
7.
commit
8.
show pim [vrf vrf-name] [ipv4 | ipv6] [{unicast | multicast | safi-all} topology {table-name | all}] rpf
[ip-address | hash | summary | route-policy]
