PurposeCommand or Action
(Optional) Displays group-to-PIM mode mapping.
show pim [ipv4 | ipv6] group-map [ip-address-name]
[info-source]
Step 8
Example:
RP/0/RP0/CPU0:router# show pim ipv4 group-map
(Optional) Displays PIM topology table information for a
specific group or all groups.
show pim [vrf vrf-name] [ipv4 | ipv6] topology
[source-ip-address [group-ip-address] | entry-flag
flag | interface-flag | summary] [route-count]
Step 9
Example:
RP/0/RP0/CPU0:router# show pim topology
Configuring Native PIM BIDIR
Perform these steps to configure native PIM BIDIR.
SUMMARY STEPS
1.
configure
2.
ipv4 access-list name
3.
[sequence-number] permit source [source-wildcard]
4.
interface type interface-path-id
5.
{ipv4 | ipv6} address address mask
6.
router ospf 100
7.
nsf cisco
8.
area area_id
9.
interface type interface-path-id
10.
multicast-routing [address-family {ipv4 | ipv6}]
11.
nsf
12.
rate-per-route
13.
interface all enable
14.
router pim [address-family {ipv4 | ipv6}]
15.
rp-address ip-address [group-access-list] [bidir]
16.
commit
