Configuring the mLDP User Interface for LDP Opaque VPNv4 Using the Routing Policy
SUMMARY STEPS
1.
configure
2.
route-policy mldp_policy
3.
if mldp opaque vpnv4 [2:2] then pass endif
4.
if mldp opaque vpnv4 [2:2 10.1.1.1 232.1.1.1] then pass endif
5.
end-policy
6.
commit
7.
Use the show command to verify the configuration: show running-config route-policy mldp_policy
DETAILED STEPS
PurposeCommand or Action
Enters global configuration mode.configure
Example:
RP/0/RP0/CPU0:router# configure
Step 1
Enters the Route-policy configuration mode, where you
can define the route policy.
route-policy mldp_policy
Example:
RP/0/RP0/CPU0:router(config)#route-policy
mldp_policy
Step 2
Configures the mLDP vpnv4 variable to the specified
variable.
if mldp opaque vpnv4 [2:2] then pass endif
Example:
RP/0/RP0/CPU0:router(config-rpl)# if mldp opaque
vpnv4 then pass endif
Step 3
Configures the mLDP vpnv4 variable to the specified
range of variable addresses.
if mldp opaque vpnv4 [2:2 10.1.1.1 232.1.1.1] then pass
endif
Example:
RP/0/RP0/CPU0:router(config-rpl)# if mldp opaque
vpnv4 then pass endif
Step 4
end-policy
Step 5
Example:
RP/0/RP0/CPU0:router(config-rpl)# end-policy
commit
Step 6
Example outputs are as shown:
Sun Jun 22 20:03:34.308 IST
Use the show command to verify the configuration: show
running-config route-policy mldp_policy
Step 7
route-policy mldp_policy
if mldp opaque vpnv4 2:2 10.1.1.1 232.1.1.1
then
pass
endif
