PurposeCommand or Action
(Optional) Configures the NSF timeout value for multicast
forwarding route entries under the IGMP or MLD process.
nsf lifetime seconds
Example:
RP/0/RP0/CPU0:router(config-igmp)# nsf lifetime
Step 6
30
commit
Step 7
(Optional) Displays the state of NSF operation in IGMP or
MLD.
show {igmp | mld} [ old-output] nsf
Example:
RP/0/RP0/CPU0:router# show igmp nsf
Step 8
(Optional) Displays the state of NSF operation for the MFIB
line cards.
show mfib [ipv4 | ipv6] nsf [location node-id]
Example:
RP/0/RP0/CPU0:router# show mfib nsf
Step 9
(Optional) Displays the state of NSF operation in the MRIB.show mrib [ipv4 | ipv6] [old-output] nsf
Example:
RP/0/RP0/CPU0:router# show mrib nsf
Step 10
(Optional) Displays the state of NSF operation for PIM.show pim [ipv4 | ipv6] nsf
Example:
RP/0/RP0/CPU0:router# show pim nsf
Step 11
Configuring Multicast VPN
•
Enabling a VPN for Multicast Routing, on page 101 (required)
• “Configuring BGP to Advertise VRF Routes for Multicast VPN from PE to PE” (required)
See the module “Implementing BGP on Cisco IOS XR Software in Cisco IOS XR Routing Configuration
Guide for the Cisco CRS Router.
•
Configuring an MDT Address Family Session in BGP as a PE-to- PE Protocol (optional for PIM-SM
MDT groups; required for PIM-SSM MDT groups)
See the “Configuring an MDT Address Family Session in BGP” section in Cisco IOS XR Routing
Configuration Guide for the Cisco CRS Router.
•
Configuring a provider-edge-to-customer-edge protocol (optional)
Cisco IOS XR Multicast Configuration Guide for the Cisco CRS Router, Release 5.2.x
100
Implementing Multicast Routing on Cisco IOS XR Software
Configuring Multicast VPN
