Data-MDTBGP-ADOpaque-valueNameProfile
Number
N/AN/ARD:S,GVRF Inband MLDP6
N/AN/AS,GGlobal Inband7
N/AN/AN/AGlobal P2MP TE8
PIM or BGP-AD
(knob controlled)
•
Intra-AS MI- PMSI
•
S- PMSI for
Data-MDT
Type 2 -
RootAddresss:VPN -
ID:0 -n
Rosen MLDP with
BGP -AD
9
Configuration Process for MLDP MVPN (Intranet)
These steps provide a broad outline of the different configuration process of MLDP MVPN for intranet:
For detailed summary of the various MVPN profiles, see the Summary of Supported MVPN Profiles, on
page 38.
Note
•
Enabling MPLS MLDP
◦
configure
◦
mpls ldp mldp
•
Configuring a VRF entry
◦
configure
◦
vrf vrf_name
◦
address-family ipv4/ipv6 unicast
◦
import route-target route-target-ext-community
◦
export route-target route-target-ext-community
•
Configuring VPN ID
◦
configure
◦
vrf vrf_name
◦
vpn id vpn_id
The configuring VPN ID procedure is needed for profiles 1 and 9 (Rosen MLDP).
•
Configuring MVPN Routing and Forwarding instance
◦
configure
