MLDP In-band signalling supports transiting PIM (S,G) or (*,G) trees across a MPLS core without the need
for an out-of-band protocol. In-band signaling is only supported for shared-tree-only forwarding (also known
as sparse-mode threshold infinity). PIM Sparse-mode behavior is not supported (switching from (*,G) to
(S,G).
The details of the MLDP profiles are discussed in the Cisco IOS XR Multicast Configuration Guide for the
Cisco CRS Router
Summary of Supported MVPN Profiles
This tables summarizes the supported MVPN profiles:
Data-MDTBGP-ADOpaque-valueNameProfile
Number
PIM TLVs over
default MDT
N/AN/ARosen GRE0
PIM TLVs over
default MDT
N/AType 2 - Root
Address:VPN-ID:0-n
Rosen MLDP1
N/AN/ACisco proprietary -
Source- PE:RD:0
MS- PMSI (Partition)
MLDP MP2MP
2
PIM or BGP -AD
(knob controlled)
•
Intra-AS MI- PMSI
•
S- PMSI for
Data-MDT
N/ARosen GRE with BGP
-AD
3
BGP-AD
•
I- PMSI with
empty PTA
•
MS- PMSI for
partition mdt
•
S- PMSI for
data-mdt
•
S- PMSI cust
RP-discovery trees
Type 1 - Source-
PE:Global -ID
MS- PMSI (Partition)
MLDP MP2MP with
BGP -AD
4
BGP-AD
•
I- PMSI with
empty PTA
•
MS- PMSI for
partition mdt
•
S- PMSI for
data-mdt
•
S- PMSI cust
RP-discovery trees
Type 1 - Source-
PE:Global -ID
MS- PMSI (Partition)
MLDP P2MP with
BGP -AD
5
