Read the Default Status Screen
Read the Default Status Screen
The Default Status screen provides status information such as the channel frequency
setting, IF level settings, modulation type, and the number of active alarms for the
GoQAM unit. The IF GoQAM displays the default status screen after one of the
following occurs:
The reset process is complete.
You press ENTER to complete a command.
The following is an example of the Default Status screen.
IF1 44.00 MHz 30.0 dBmV
ITUB 64QAM Alarm 0
Reading the Default Status Screen
The following table describes the information displayed on the Default Status screen.
Display Function
IF1 Current IF Channel output selected. The IF number
corresponds to the channel number
Note: The GoQAM uses only IF1 and IF2.
44.00 MHz Established IF frequency setting for the selected IF
modulator
30.00 dBmV Configured IF power level setting
Note: The range for IF power level is 27.00 dBmV
to 37.00 dBmV.
ITUB 64QAM Selected modulation type. Values are:
ITUB 64 QAM
ITUB 256 QAM
DAVIC 256 QAM
DAVIC 16 QAM
DAVIC 64 QAM
Alarm 0 Current number of active alarms
