Connect the DVB ASI Input Ports
Description
The GoQAM uses ASI input pairs to receive data from ASI-compliant transmitting
devices such as Integrated Receiver Transcoders (IRTs) and MPEG multiplexers.
These ASI inputs conform to the DVB document A010. The DVB ASI Input ports are
BNC-type connectors and connect to 75 Ω coaxial cables. Each DVB ASI Input port
allows for the input of MPEG-2 transport stream (TS) data at a maximum rate of 216
Mbps.
Location of DVB ASI Input Ports
The following illustration shows an example of an IF GoQAM connected to DVB ASI
sources.
