Set Up UpConverter Basic Parameters
The UpConverter Name is the name assigned to the upconverter.
Ports
The following table lists the Set Up UpConverter Ports field descriptions.
Field Description
Reserved TSID Range Displays the available range of transport stream
IDs
50 – 45000 for Overlay systems
11 – 50999 for Regional Control System (RCS)
Input UpConverter Stream
ID
Displays the transport stream ID of the currently
selected upconverter
RF Output Ports
The following table lists the Set Up UpConverter RF Output Ports field descriptions.
Field Description
Modulation Displays the frequency modulation for the RF
Output ports
Note: The default is 64-QAM for ITU J.83
Annex B.
Transport Stream ID Displays the identifier of the transport stream
ID for each RF Output ports
Channel Center Frequency
(MHz)
Displays the frequency assigned to the
upconverter
Continuous Wave Mode This option is not operational at this time.
Mute RF Output This option is not operational at this time.
Function Keys
The following table describes the function keys on the Set Up UpConverter window.
Field Description
Add Allows you to add a new RF Output port
Open Allows you to edit an RF Output port
Delete Allows you to delete an RF Output port
Save Saves changes and closes the window
Apply Makes changes without closing the window
