Cisco GoQAM User Manual

Appendix A
Technical Specifications
150 4004834 Rev D
Installation and Operation Requirements
This section contains tables that define specifications specific to installing and
operating the GoQAM.
Power Requirements Table
The following table describes the power specifications for the GoQAM.
Item Specification
Supply Voltage

90V to 130V AC @ 47 to 63 Hz (AC unit)

180V to 264V AC @ 47 to 63 Hz (AC unit)

–42V to –57V DC (DC unit)
Fuses

4.0 A SLO BLO 250V (AC unit)

6.3 A SLO BLO 250V (DC unit)
Line Frequency

47 to 63 Hz (AC unit only)
Power Required

RF GoQAM: 155 VA (typical)

IF GoQAM: 85 VA (typical)
Power Dissipated

RF GoQAM: 151 Watts (typical)

IF GoQAM: 80 Watts (typical)
In Rush Current

35 amps maximum, Vin = 130V AC (AC unit)

75 amps maximum, Vin = 264V AC (AC unit)

15 amps maximum, Vin = -57V DC (DC unit)
Rack Requirements Table
Item Specification
Rack Mount Type EIA RS-310
Height 1.75 in./44.45 mm
Width 19 in./482.6 mm
Depth 22.5 in./571.5 mm
Weight 13.5 lb./5.4 kg
