IF Specifications
IF Specifications Table
The following table provides various IF specifications and ranges for the IF GoQAM.
Specification Range
Frequency Range 44.00 MHz
Minimum Tuning Step Size N/A
Output Power Level +27 to +37 dBmV minimum range
Output Impedance 75 Ω
Spurious Outputs (44 MHz to ± 20 MHz)
single frequency modulated output related
Less than -60 dB (relative to the average
power of the QAM channel with the
highest power level)
Phase Noise -100 dBc/Hz 10 kHz from carrier
-100 dBc/Hz 10 kHz from carrier
(typical)
Output Frequency Error (over temperature) Less than 3 ppm
