Understand the IF GoQAM GUIs
This section provides examples and descriptions of the GUIs used for provisioning
the IF GoQAM as a DBDS network element an Overlay environment.
Important! Actual GUIs may differ slightly from the GUIs presented in this guide.
File Selection Dialog Screen
The following table lists field descriptions on the File Selection Dialog screen.
Field Description
Filter Displays the path and filename wildcard used by the system to search
for files. Enter the UNIX path, ending with /*.
This field displays the contents of the directory in the Directories and
Files fields of this window when you click Filter.
Directories Displays a list of available directories at the current path specified in
the Filter field
Files Displays a list of files within the current path specified in the Filter
field
Selection Displays the selected file
Understanding the IF GoQAM GUIs
Use the DNCS IF GoQAM GUIs to provision the IF GoQAM on the DNCS. The main
GUIs are the Set Up IF GOQAM window, the UpConverter List window, and the Set
Up UpConverter window. The following list provides descriptions of the IF GoQAM
GUIs:
The Set Up IF GOQAM window contains the following fields:
- Basic Parameters
- Advanced Parameters
- Connectivity
The UpConverter List window contains the UpConverter Name fields
The Set Up UpConverter window contains the following fields:
- Basic Parameters
- Connectivity
Note: The sections within this chapter include examples and descriptions of all of the
fields within these windows.
