Figure 30: QSFP-DD Transceiver Module (Optical)
Bale clasp latch1
QSFP-DD transceiver body2
Figure 31: QSFP-DD Transceiver Module (Optical)
Cisco Network Convergence System 540 Large Density Routers Hardware Installation Guide
51
Install the Device
Install and Remove QSFP+, QSFP28, or QSFP-DD Transceiver Modules
