Cisco NCS 5000 Series Hardware Installation Guide

Procedure
Step 1
On Cisco NCS 5001 and NCS 5011 remove the label on the rear side (fan side) of the router to expose the
ground mounting holes (as shown in the figure). On Cisco NCS 5002, remove the label on the right side of
the front side (port side) of the router to expose the ground mounting holes (as shown in the figure).
Figure 14: Grounding the Cisco NCS 5001 Router
2 - Ground Lug bracket1 - Ground Lug
3 - Label
Hardware Installation Guide for Cisco NCS 5000 Series Routers
28
Installing the NCS 5000 Router
Grounding Cisco NCS 5000
