Cisco NCS 5000 Series Hardware Installation Guide

Installing Cisco NCS 5011
This section describes how to use the rack-mount kit provided with the router to install the Cisco NCS 5011
router into a cabinet or rack that meets the requirements described in Cabinet and Rack Installation , on page
45.
Caution
If the rack is on wheels, ensure that the brakes are engaged or that the rack is otherwise stabilized.
Note
The following table lists the items contained in the rack-mount kit provided with the Cisco NCS 5011 router.
Table 10: Cisco NCS 5011 Router Rack-Mount Kit
Part DescriptionQuantity
Rack-mount brackets4
M4 x 0.7 x 7-mm Phillips flat-head screws16
Rack-mount guides4
Slider rails2
Procedure
Step 1
Install the front rack-mount brackets on the router as follows:
a) Determine which end of the chassis is to be located in the cold aisle as follows:
•
If the switch has port-side intake modules, position the module so that its ports will be in the cold
aisle.
•
If the switch has port-side exhaust modules, position the module so that its fan and power supply
modules will be in the cold aisle.
b) Position a front rack-mount bracket so that four of its screw holes are aligned to the screw holes on the
side of the router, and then use four M4 screws to attach the bracket to the router.
You can align any four of the holes in the front rack-mount bracket to four of the six screw holes
in the chassis. The holes that you use depend on the requirements of your rack.
Note
Hardware Installation Guide for Cisco NCS 5000 Series Routers
25
Installing the NCS 5000 Router
Installing Cisco NCS 5011
