Cisco NCS 5000 Series Hardware Installation Guide

Installing Cisco NCS 5002
This section describes how to use the rack-mount kit provided with the router to install the Cisco NCS 5002
router into a cabinet or rack that meets the requirements described in Cabinet and Rack Installation , on page
45.
Caution
If the rack is on wheels, ensure that the brakes are engaged or that the rack is otherwise stabilized.
Note
The following table lists the items contained in the rack-mount kit provided with the Cisco NCS 5002 router.
Table 9: Cisco NCS 5002 Router Rack-Mount Kit
Part DescriptionQuantity
Rack-mount brackets4
M4 x 0.7 x 7-mm Phillips flat-head screws16
Rack-mount guides4
Slider rails2
Procedure
Step 1
Install the front rack-mount brackets on the router as follows:
a) Position a front rack-mount bracket on the side of the router with its two holes aligned to two holes on the
front side of the router, and then use two M4 screws to attach the bracket to the router.
Hardware Installation Guide for Cisco NCS 5000 Series Routers
21
Installing the NCS 5000 Router
Installing Cisco NCS 5002
