Page #26 background imageLoading...
Page #26 background image
Caution
To prevent loss of input power, ensure the total maximum loads on the circuits supplying power to the
router are within the current ratings for the wiring and breakers.
Note
Installing Cisco NCS 5000
The following sections describe how to install the Cisco NCS 5000 Series routers.
Installing Cisco NCS 5001
This section describes how to use the rack-mount kit provided with the router to install the Cisco NCS 5001
router into a cabinet or rack that meets the requirements described in Cabinet and Rack Installation , on page
45.
Warning
If the rack is on wheels, ensure that the brakes are engaged or that the rack is otherwise stabilized.
Note
The following table lists the items contained in the rack-mount kit provided with the Cisco NCS 5001 router.
Table 8: Cisco NCS 5001 Router Rack-Mount Kit
Part DescriptionQuantity
Rack-mount brackets4
M4 x 0.7 x 7-mm Phillips flat-head screws16
Rack-mount guides4
Slider rails2
Procedure
Step 1
Install the front rack-mount brackets on the chassis as follows:
a) Position a front rack-mount bracket on the side of the chassis with its four holes aligned to four of the six
screw holes on the front side of the chassis, and then use four M4 screws to attach the bracket to the chassis.
You can align any four of the holes in the front rack-mount bracket to four of the six screw holes
in the chassis. The holes that you use depend on the requirements of your rack.
Note
Hardware Installation Guide for Cisco NCS 5000 Series Routers
18
Installing the NCS 5000 Router
Installing Cisco NCS 5000
