Cisco NCS 540 Hardware Installation Guide

SignalRJ-45 Pin
—2
Tx3
Ground (GND)4
GND5
Rx6
—7
—8
Connect to the Management Ethernet Port
You must complete the initial router configuration.
The management Ethernet port provides out-of-band management, which enables you to use the Command
Line Interface (CLI) to manage the router by its IP address. This port uses a 10/100/1000 Ethernet connection
with an RJ-45 interface.
To prevent an IP address conflict, do not connect the management Ethernet port until the initial configuration
is complete.
Note
To connect cables to the system management port, attach Category 5 cables directly to the RJ-45 receptacle
on the management Ethernet port.
Cisco Network Convergence System 540 Large Density Routers Hardware Installation Guide
42
Install the Device
Connect to the Management Ethernet Port

Cisco NCS 540 Specifications

General

Operating System	Cisco IOS XR
Memory	16 GB DDR4
Storage	128 GB SSD
Ports	Multiple 1G/10G/40G/100G Ethernet ports
Forwarding Capacity	800 Gbps
Redundancy	Redundant power supplies and fans
Form Factor	1 RU
Operating Relative Humidity	5% to 95% noncondensing
Input Voltage	100-240 VAC, 50-60 Hz
Power Supply	AC or DC
Processor	Quad-core 2.4 GHz
