Cisco NCS 540 Hardware Installation Guide

StatusColorLED
Time core is synchronized to an external source including
IEEE1588.
GreenSYNC
System is in Synchronous Ethernet mode.Flashing Green
Acquiring state or Holdover: Time core is in acquiring
state or holdover mode.
Amber
Time core clock synchronization is disabled or in
free-running state.
Off
GNSS is not configured.
OffGNSS
GNSS Normal State. Self-survey is complete.Green
Power up. GNSS is not tracking any satellite.Red
Auto holdover.Amber
Learning state–normal. Self-survey is not completed.Flashing Green
System Fans LED
Cisco N540-24Q8L2DD-SYS has six fans at the back panel.
Table 9: Fan Assembly LED Descriptions
StatusColorLED
Fans are operating normally.GreenSTATUS
Single fan failure.Amber
More than one fan failure or a single PSU fan failure.Red
Fan tray is not receiving power.Off
Cisco Network Convergence System 540 Large Density Routers Hardware Installation Guide
66
Appendix
System Fans LED

Cisco NCS 540 Specifications

General

Operating System	Cisco IOS XR
Memory	16 GB DDR4
Storage	128 GB SSD
Ports	Multiple 1G/10G/40G/100G Ethernet ports
Forwarding Capacity	800 Gbps
Redundancy	Redundant power supplies and fans
Form Factor	1 RU
Operating Relative Humidity	5% to 95% noncondensing
Input Voltage	100-240 VAC, 50-60 Hz
Power Supply	AC or DC
Processor	Quad-core 2.4 GHz
