Cisco Nexus 7000 - Connecting or Disconnecting a 1000 BASE-T Port

7-9
Cisco Nexus 7000 Series Hardware Installation and Reference Guide
OL-23069-07
Chapter 7 Connecting the Cisco Nexus 7000 Series Switch to the Network
Connecting an I/O Module
This section includes the following topics:
• Connecting or Disconnecting a 1000BASE-T Port, page 7-9
• Connecting or Disconnecting an SFP, SFP+, or X2 Port, page 7-10
Connecting or Disconnecting a 1000BASE-T Port
This section includes the following topics:
• Connecting a 1000BASE-T Port to the Network, page 7-10
• Disconnecting a 1000BASE-T Port from the Network, page 7-10
8-port 10-Gigabit Ethernet (N7K-M108X2-12L) 10GBASE-X X2
10GBASE-X2
10GBASE-X SFP+
X2-10GB-ER
X2-10GB-LR
X2-10GB-LRM/
X2-10GB-LX4
X2-10GB-SR
X2-10GB-ZR
X2-10GB-CX4
DWDM-xxxx
SFP-10G-LR
3
SFP-10G-LRM
3
SFP-10G-SR
3
SFP-H10GB-CUxM
3
Fiber optic
Copper
Copper
Fiber optic
24-port 10-Gigabit Ethernet (N7K-M224XP-23L) 10GBASE-X SFP+ DWDM-SFP10G-xx.xx
FET-10G
SFP-10G-ER
SFP-10G-LR
SFP-10G-LRM
SFP-10G-SR
SFP-10G-ZR
2
SFP-H10GB-CUxM
SFP-H10GB-ACUxM
Fiber optic
Copper
6-Port 40-Gigabit Ethernet (N7K-M206FQ-23L) QSFP-40G-LR4
QSFP-40G-SR4
Fiber optic
2-Port 100-Gigabit Ethernet (N7K-M202CF-22L) CFP-100G-LR4
CFP-100G-SR10
CFP-40G-LR4
CFP-40G-SR4
Fiber optic
1. FETs are used only when connecting this I/O module to a Fabric Extender (FEX).
2. Requires Version 2 or later version.
3. Requires the CVR-X2-SFP10G OneX Converter Module (X2 to SFP+ adapter)
Table 7-1 Connectors and Cables Supported by I/O Modules (continued)
Module Port Type Connector/Transceiver Cable Type
