Appendix 8 Managing the Switch Hardware
Information About Modules
I/O Modules
Cisco Nexus 7000 Series switches support the following I/O modules:
• F1-Series 32-port 1- and 10-Gigabit Ethernet I/O modules (N7K-F132XP-15)
1
• F2-Series 48-port 1-/10-Gigabit Ethernet I/O modules with XL (N7K-F248XP-25)
• F2-Series 48-port 1-/10-Gigabit Ethernet I/O modules with XL and enhancements
(N7K-F248XP-25E)
• M1-Series 48-port 10/100/1000 I/O modules (N7K-M148GT-11)
1
• M1-Series 48-port 10/100/1000 I/O modules with XL option (N7K-M148GT-11L)
• M1-Series 48-port 1-Gigabit Ethernet I/O modules (N7K-M148GS-11)
1
• M1-Series 48-port 1-Gigabit Ethernet I/O modules with XL option (N7K-M148GS-11L)
• M1-Series 32-port 10-Gigabit Ethernet I/O modules (N7K-M132XP-12)
1
sup-1 and sup-2
Fixed usage Cisco Nexus 7004 and 7009
• sup-1 refers to the supervisor module in slot 1.
• sup-2 refers to the supervisor module in slot 2.
Cisco Nexus 7010
• sup-1 refers to the supervisor module in slot 5.
• sub-2 refers to the supervisor module in slot 6.
Cisco Nexus 7018
• sup-1 refers to the supervisor module in slot 9.
• sup-2 refers to the supervisor module in slot 10.
sup-active and sup-standby
Relative usage Cisco Nexus 7004, 7009, 7010, and Cisco Nexus 7018
• sup-active refers to the active supervisor module—relative to the
slot that contains the active supervisor module.
• sup-standby refers to the standby supervisor module—relative to
the slot that contains the standby supervisor module.
sup-local and sup-remote
Relative usage If you are logged into the active supervisor (in any Cisco Nexus 7000
Series chassis), the following applies:
• sup-local refers to the active supervisor module.
• sup-remote refers to the standby supervisor module.
If you are logged into the standby supervisor (in any Cisco Nexus
7000 Series chassis), the following applies:
• sup-local refers to the standby supervisor module (the one that
you are logged into).
• There is no sup-remote available from the standby supervisor
module (you cannot access a file system on the active supervisor).
Table 8-5 Supervisor Module Terms and Usage in Console Displays (continued)
Module Terms Fixed or Relative Usage
1. Not supported by the Cisco Nexus 7004 switch.
