C-7

Cisco Nexus 7000 Series Hardware Installation and Reference Guide

OL-23069-07

Appendix C Accessory Kits Contents

Cisco Nexus 7010 Switch Accessory Kits

Table C-6 lists and illustrates the accessory kit contents for the Cisco Nexus 7010 switch.

Table C-6 Cisco Nexus 7010 System Accessory Kit Contents

Illustration Description Quantity

Bottom support rails kit (includes the following

parts):

• 12-24 x 3/4-in. Phillips screws

• M6 x 19-mm Phillips screws

• Adjustable bottom support rails

1 kit

20 per kit

2 per kit

RJ-45 rollover cable 1

DB-9F/RJ-45F PC terminal 1

Ground lug kit (includes the following parts):

• Two-hole lug

• M4 x 8-mm Phillips pan-head screws

1 kit

1 per kit

2 per kit

Cable ties, 8.5 inches 1 kit

(10 pieces)

195377

196530

196531

185847

Ground lug kit

186697
