Physical Specifications for the Cisco Nexus 7000 Series Chassis

The physical specifications differ for the Cisco Nexus 7000 Series chassis depending on the model that

you are installing and the type of installation you are doing (you can front mount all models but you can

optionally do a center mount of the Cisco Nexus 7004 and 7009 chassis). Table A-2 lists the physical

specifications for each model and installation type.

The weights and quantities are listed in the following tables:

• Cisco Nexus 7004 switch (see Table A-3)

• Cisco Nexus 7009 switch (see Table A-4 on page A-3)

• Cisco Nexus 7010 switch (see Table A-5 on page A-5)

• Cisco Nexus 7018 switch (see Table A-6 on page A-6)

Noise Sound pressure levels

Without air filter 70 dBA 63.6 dBA 67.2 dBA 65.0 dBA

With air filter — — 70.2 dBA —

Sound power levels

Without air filter 83 dBA 72.5 dBA 78.9 dBA 74.2 dBA

With air filter — — 81.7 dBA —

Table A-1 Environmental Specifications for the Cisco Nexus 7000 Series Switches (continued)

Description Cisco Nexus 7004 Cisco Nexus 7009 Cisco Nexus 7010 Cisco Nexus 7018

Table A-2 Physical Specifications for Cisco Nexus 7000 Series Chassis

Chassis Width

Front Depth

Rear Depth

Height

Cisco Nexus 7004

(all mounts)

17.3 inches (43.9 cm) 7 inches (17.8 cm) 24.0 inches (61.0 cm) 12.2 inches (30.9 cm) (7 RU)

Cisco Nexus 7009

(front mount)

17.3 inches (43.9 cm) 7 inches (17.8 cm) 24.0 inches (61.0 cm) 24.5 inches (62.2 cm) (14 RU)

Cisco Nexus 7009

(center mount)

17.3 inches (43.9 cm) 13 inches (33.0 cm) 18.0 inches (45.8 cm) 24.5 inches (62.2 cm) (14 RU)

Cisco Nexus 7010

(all mounts)

17.3 inches (43.9 cm) 7 inches (17.8 cm) 32.0 inches (81.3 cm) 36.75 inches (93.3 cm) (21.0 RU)

Cisco Nexus 7018

(all mounts

17.3 inches (43.9 cm) 7 inches (17.8 cm) 32.0 inches (81.3 cm) 43.75 inches (111.1 cm) (25.0 RU)

1. Width is also the minimal clearance required between the two vertical mounting rails inside the rack or cabinet.

2. Front depth is also the minimal clearance required between the front mounting rails and the inside of the front of the rack or cabinet. For all switches, this

includes 7 inches (17.8 cm) of space for cabling. For the Cisco Nexus 7009 center-mounted chassis, this distance also includes 6 inches of the chassis

which is offset to the front by the center-mount bracket.

3. Rear depth is also the clearance required between the front-mounting rails and the inside of the rear of the rack or cabinet. For front mounted switches,

this is the same as the depth of the chassis. For a center-mounted Cisco Nexus 7009 switch, this is 6 inches (15.2 cm) less than the depth of the chassis,

which is offset to the front.

4. Height is also the clearance required between the top of the bottom support bracket and the top of the chassis that you are installing. If you are installing

another chassis above this chassis, its bottom-support brackets must be positioned above this clearance area.
