1-3
Cisco Nexus 7000 Series Hardware Installation and Reference Guide
OL-23069-07
Chapter 1 Overview
Cisco Nexus 7000 Series
1 Air intake areas for up to four AC or DC power
supplies (N7K-AC-3KW or N7K-DC-3KW) or blank
filler plates in place of missing power supplies to
maintain the designed airflow
5 Fan tray
2 Cable management side frames 6 Handles used for moving the chassis (reduce the chassis
weight to less than 120 lbs (54.4 kg) in order to use these
handles to lift the chassis)
4 I/O or NAM modules (1 to 2 modules in slots 3 to 4).
These modules are a combination of the following:
• F2 Series
–
48-port 1-/10-Gigabit SFP+ with XL option
and FEX support (N7K-F248XP-25 and
N7K-F248XP-25E
1
)
–
48-port 1-/10-GBASE-T with XL option
(N7K-F248XT-25E)
• M1 Series
–
48-port 10/100/1000 with XL option
(N7K-M148GT-11L)
–
48-port 1-Gigabit Ethernet with XL option
(N7K-M148GS-11L)
–
32-port 10-Gigabit Ethernet with XL option
and FEX support (N7K-M132XP-12L)
–
8-port 10-Gigabit Ethernet with XL option
(N7K-M108X2-12L)
• M2 Series
–
24-port 10-Gigabit Ethernet with XL option
and FEX support (N7K-M224XP-23L)
–
6-port 40-Gigabit Ethernet with XL option
(N7K-M206XP-23L)
–
2-port 100-Gigabit Ethernet with XL option
(N7K-M202XP-23L)
Alternatively, one or more of these slots can be used
for Network Analysis Modules (NAMs)
(N7K-SM-NAM-K9).
7 Air intake areas for supervisor and I/O modules
4 Supervisor modules (1 or 2 modules in slots 1 and 2).
These modules are of only one of the following types
(if installing two supervisor modules, both modules
must be the same type with the same amount of
memory):
• Supervisor 2 (N7K-SUP2)
• Supervisor 2 Enhanced (N7K-SUP2E)
1. The Cisco Nexus F2-Series 48-port 1/10-Gigabit SFP+ module supports all of the standard features of F2 modules and it functions like an F2-series
module with Layer 2 and Layer 3 enabled. These modules also support IPv6 DSCP-to-Queue mapping.
