10-26
Cisco Nexus 7000 Series Hardware Installation and Reference Guide
OL-23069-07
Chapter 10 Installing or Replacing Components
Replacing a Supervisor Module
This setup utility will guide you through the basic configuration of
the system. Setup configures only enough connectivity for management
of the system.
Please register Cisco Nexus7000 Family devices promptly with your
supplier. Failure to register may affect response times for initial
service calls. Nexus7000 devices must be registered to receive
entitled support services.
Press Enter at anytime to skip a dialog. Use ctrl-c at anytime
to skip the remaining dialogs.
Would you like to enter the basic configuration dialog (yes/no): no
Step 15 When asked to log in, enter the login and password that you specified in step 12.
User Access Verification
switch login:
Password:
Step 16 Verify that the switch is running the required version of the NX-OS software by using the show version
command.
switch(config)# show version
Note If the version of NX-OS is not the same as you intended to use, copy the previously saved images from
the USB drive in SLOT 0 to bootflash: and perform an upgrade to the appropriate version. For more
information, see the Cisco Nexus 7000 Series NX-OS Software Upgrade and Downgrade Guide.
Step 17 Copy the TAR archive containing the license files from the USB SLOT 0 drive to bootflash:, extract the
archive, and install the licenses by using the copy, tar extract, and install license commands. Repeat
the install license command for each extracted license file.
switch(config)# copy slot0:licenses_archive_file_name.tar bootflash:
switch(config)# tar extract bootflash:
licenses_archive_file_name.tar to bootflash:
switch(config)# install license bootflash:
license_file_name.lic
Note The tar extract command requires that the TAR file be located in bootflash: or volatile:.
Step 18 Make sure that all I/O modules are online and that the standby supervisor is in ha-standby mode by using
the show module command.
switch(config)# show module
Mod Ports Module-Type Model Status
--- ----- ----------------------------------- ------------------ ---------------
2 0 Supervisor module-2 N7K-SUP2E active *
6 0 Supervisor module-2 N7K-SUP2E ha-standby
7 48 1/10 Gbps Ethernet Module N7K-F248XP-25 ok
...
Step 19 If there are Fabric 2 modules in the switch, upgrade the Fabric 2 EPLDs (see the “Configuring EPLDs”
section on page 8-34).
Step 20 Restore the previously saved configurations by using the copy command to copy the configuration file
in the USB drive to the running configuration.
switch(config)# copy slot0:configuration_file_name running-config
