Chapter 1 Overview
Cisco Nexus 7000 Series
1 Door for the cable management
area
5 Handles used to reposition the chassis (do not lift the chassis with these
handles—use a mechanical lift)
2 System status LEDs 6 I/O or NAM modules (1 to 8 modules in slots 1 to 4 and 7 to 10). These modules
are a combination of the following:
• F1 Series
–
32-port 1- and 10-Gigabit Ethernet I/O modules (N7K-F132XP-15)
• F2 Series
–
48-port 1-/10-Gigabit SFP+ with XL option and FEX support
(N7K-F248XP-25 and N7K-F248XP-25E
1
)
–
48-port 1-/10-GBASE-T with XL option (N7K-F248XT-25E)
• M1 Series
–
10/100/1000 I/O modules (N7K-M148GT-11)
–
48-port 10/100/1000 I/O modules with XL option (N7K-M148GT-11L)
–
48-port 1-Gigabit Ethernet I/O modules (N7K-M148GS-11)
–
48-port 1-Gigabit Ethernet I/O modules with XL option
(N7K-M148GS-11L)
–
32-port 10-Gigabit Ethernet I/O modules with FEX support
(N7K-M132XP-12)
–
32-port 10-Gigabit Ethernet I/O modules with XL option and FEX
support (N7K-M132XP-12L)
–
8-port 10-Gigabit Ethernet I/O modules with XL option
(N7K-M108X2-12L)
• M2 Series
–
24-port 10-Gigabit Ethernet I/O modules with XL option and FEX
support (N7K-M224XP-23L)
–
6-port 40-Gigabit Ethernet I/O modules with XL option
(N7K-M206XP-23L)
–
2-port 100-Gigabit Ethernet I/O modules with XL option
(N7K-M202XP-23L)
Alternatively, one or more of these slots can be used for Network Analysis
Modules (NAMs) (N7K-SM-NAM-K9).
3 Cable management area (upper
routing portion can be removed if
necessary)
7 Supervisor modules (1 or 2 modules in slots 5 and 6). These modules are of only
one of the following types (if installing two supervisor modules, both modules
must be the same type with the same amount of memory):
• Supervisor 1 (N7K-SUP1)
• Supervisor 2 (N7K-SUP2)
• Supervisor 2 Enhanced (N7K-SUP2E)
4 Rack-mount bracket (2) (one on
each side)
8 Air intake (shown without the optional air filter)
1. The Cisco Nexus F2-Series 48-port 1/10-Gigabit SFP+ module supports all of the standard features of F2 modules and it functions like an F2-series
module with Layer 2 and Layer 3 enabled. These modules also support IPv6 DSCP-to-Queue mapping.
