Physical Specifications for the Cisco Nexus 7000 Series Chassis
Supervisor modules — 1 or 2
(same type
if using 2)
Supervisor 1 (N7K-SUP1) 9.9 lb (4.5 kg)
Supervisor 2 (N7K-SUP2) 10.4 lb (4.7 kg)
Supervisor 2 Enhanced (N7K-SUP2E) 11.7 lb (5.3 kg)
F1 I/O Modules —1 to 7
(can mix
I/O module
types)
32-port 1- and 10-Gigabit Ethernet I/O module (N7K-F132XP-15) 14.0 lb (6.4 kg)
F2 I/O Modules —
48-port 1- and 10-Gigabit Ethernet I/O module (N7K-F248XP-25 and N7K-F248XP-25E) 14.0 lb (6.4 kg)
48-port 1- and 10-GBASE-T I/O module (N7K-F248XT-25E) 14.0 lb (6.4 kg)
M1 I/O Modules —
48-port 10/100/1000 Ethernet I/O module (N7K-M148GT-11) 14 lb (6.4 kg)
48-port 10/100/1000 Ethernet I/O module (N7K-M148GT-11L) 14 lb (6.4 kg)
48-port 1-Gigabit Ethernet I/O module (N7K-M148GS-11) 15.5 lb (7.0 kg)
48-port 1-Gigabit Ethernet I/O module with XL option (N7K-M148GS-11L) 15.5 lb (7.0 kg)
32-port 10-Gigabit Ethernet I/O module (N7K-M132XP-12) 17.0 lb (7.7 kg)
32-port 10-Gigabit Ethernet I/O module with XL option (N7K-M132XP-12L) 17.0 lb (7.7 kg)
8-port 10-Gigabit Ethernet I/O module with XL option (N7K-M108X2-12L) 14.0 lb (6.4 kg)
M2 I/O Modules —
24-port 10-Gigabit Ethernet I/O module with XL option (N7K-M224XP-23L) 16.5 lb (7.5 kg)
6-port 40-Gigabit Ethernet I/O module with XL option (N7K-M206FQ-23L) 16.5 lb (7.5 kg)
2-port 100-Gigabit Ethernet I/O module with XL option (N7K-M202CF-22L) 17.0 lb (7.7 kg)
Service Modules — 0 or 1+
NAM (N7K-SM-NAM-K9) 17.9 lbs. (8.1 kg)
Fabric Modules —For F2 I/O,
use 5.
For F1,
M1, and
M2 I/O,
use 3 to 5.
Fabric-2 module (N7K-C7009-FAB-2) 5 lb (2.27 kg)
Fan tray (N7K-C7009-FAN) 25.0 lb (11.3 kg) 1
Power Supplies — 1 or 2
(can mix
power
supply
types)
6-kW AC power supply unit (N7K-AC-6.0KW) 18 lb (8.2 kg)
7.5-kW AC power supply unit (N7K-AC-7.5KW-INT and N7K-AC-7.5KW-US) 26 lb (11.8 kg)
6-kW DC power supply unit (N7K-DC-6.0KW) 21 lb (9.5 kg)
DC Power Interface Unit 5 lb (2.3 kg) 0 to 2
Optional Components — —
Door and air frame (optional) — 0 or 1
Table A-4 Weights and Quantities for the Cisco Nexus 7009 Switch Components (continued)
Component Weight per Unit Quantity
