A-6
Cisco Nexus 7000 Series Hardware Installation and Reference Guide
OL-23069-07
Appendix A Technical Specifications
Physical Specifications for the Cisco Nexus 7000 Series Chassis
Fabric Modules —For F2 I/O,
use 5.
For F1, M1,
and M2
I/O, use 3
to 5.
Fabric-1 module (N7K-C7010-FAB-1) 4 lb (1.8 kg)
Fabric-2 module (N7K-C7010-FAB-2) 4 lb (1.8 kg)
Fan Trays ——
System fan tray (N7K-C7010-FAN-S) 20 lb (9.1 kg) 2
Fabric fan tray (N7K-C7010-FAN-F) 5 lb (2.3 kg) 2
Power Supplies —2 to 3
(can mix
power
supply
types)
6-kW AC power supply unit (N7K-AC-6.0KW) 18 lb (8.2 kg)
7.5-kW AC power supply unit (N7K-AC-7.5KW-INT and N7K-AC-7.5KW-US) 26 lb (11.8 kg)
6-kW DC power supply unit (N7K-DC-6.0KW) 21 lb (9.5 kg)
DC Power Interface Unit 5 lb (2.3 kg) 0 to 2
Optional Components — —
Mid-frame doors and frame — 0 or 1
Table A-6 Weights and Quantities for the Cisco Nexus 7018 Components
Component Weight per Unit Quantity
Chassis 187 lb (85.0 kg) 1
Supervisor Modules — 1 or 2
(same type
if using 2)
Supervisor 1 (N7K-SUP1) 9.9 lb (4.5 kg)
Supervisor 2 (N7K-SUP2) 10.4 lb (4.7 kg)
Supervisor 2 Enhanced (N7K-SUP2E) 11.7 lb (5.3 kg)
Table A-5 Weights and Quantities for the Cisco Nexus 7010 Components (continued)
Component Weight per Unit Quantity
