A-10
Cisco Nexus 7000 Series Hardware Installation and Reference Guide
OL-23069-07
Appendix A Technical Specifications
Power Specifications for the Cisco Nexus 7000 Series Switches
F1 I/O Modules 1 to 8
(can mix
types)
——
32-port 1- and 10-Gigabit Ethernet I/O module (N7K-F132XP-15) 385 W 283 W
F2 I/O Modules ——
48-port 1- and 10-Gigabit Ethernet I/O module (N7K-F248XP-25 and
N7K-F248XP-25E)
450 W 400 W
48-port 1- and 10-GBASE-T I/O module (N7K-F248XT-25E) 550 W 420 W
M1 I/O Modules ——
48-port 10/100/1000 Ethernet I/O module (N7K-M148GT-11) 400 W 358 W
48-port 10/100/1000 Ethernet I/O module with XL option (N7K-M148GT-11L) 400 W 358 W
48-port 1-Gigabit Ethernet I/O module (N7K-M1148GS-11) 400 W 358 W
48-port 1-Gigabit Ethernet I/O module with XL option (N7K-M148GS-11L) 400 W 358 W
32-port 10-Gigabit Ethernet I/O module (N7K-M132XP-12) 750 W 611 W
32-port 10-Gigabit Ethernet I/O module with XL option (N7K-M132XP-12L) 750 W 611 W
8-port 10-Gigabit Ethernet I/O module with XL option (N7K-M108X2-12L) 650 W 520 W
M2 I/O Modules ——
24-port 10-Gigabit Ethernet I/O module with XL option (N7K-M224XP-23L) 795 W 720 W
6-port 40-Gigabit Ethernet I/O module with XL option (N7K-M206FQ-23L) 795 W 720 W
2-port 100-Gigabit Ethernet I/O module with XL option (N7K-M202CF-22L) 795 W 690 W
Fabric Modules 3 to 5
(same
type)
——
Fabric-1 module (N7K-C7010-FAB-1) 60 W 55 W
Fabric-2 module (N7K-C7010-FAB-2) 80 W 60W
Fan Trays (N7K-C7010-FAN-F and N7K-C7010-FAN-S) — — —
All fan trays (total) 2184 W 300 W
Table A-10 Power Requirements for the Cisco Nexus 7018 System Components
Component Quantity Maximum Typical
Supervisor Modules 1 or 2
(same
type if
using 2)
——
Supervisor 1 (N7K-SUP1) 210 W 190 W
Supervisor 2 (N7K-SUP2) 300 W 109 W
Supervisor 2 Enhanced (N7K-SUP2E) 300 W 147 W
Table A-9 Power Requirements for the Cisco Nexus 7010 System Components (continued)
Component Quantity Maximum Typical
