A-25
Cisco Nexus 7000 Series Hardware Installation and Reference Guide
OL-23069-07
Appendix A Technical Specifications
Chassis Clearances
Figure A-16 Clearances Required for the Cisco Nexus 7004 in a Two-Post Rack with Center-Mount
Brackets
5 Air intake from cold aisle for power supplies 12 Chassis depth
6 Air intake from cold aisle for the supervisor
and I/O modules
13 Clearance required between the front of the
chassis and the inside of the cabinet for the
cable management frames and the optional
front door
7 Air exhaust to hot aisle for all modules and
power supplies
14 Front clearance required for installing the
chassis and replacing the modules
17.3 in
(43.9 cm)
18.0 in
(45.7 cm)
12.5 in
(31.8 cm)
26.0 in
(66.0 cm)
1
7
9
10
11
12
13
1465
8
2
3
4 4
3
304035
