B-11
Cisco Nexus 7000 Series Hardware Installation and Reference Guide
OL-23069-07
Appendix B Transceivers and Module Connectors
10-Gigabit X2 Transceivers
Figure B-5 10-Gigabit X2 Transceiver (Latching Sleeve Not Extended)
Figure B-6 X2 Transceiver with Latching Sleeve Extended
1 Transmit optical bore 5 Transceiver heat sink
2 Receive optical bore 6 Module connector
3 Latching sleeve (retracted) 7 Latch (extended when sleeve is retracted)
4 EMI gasket
1 Latching sleeve (extended to remove
transceiver)
2 Latch (retracted to enable you to remove the
transceiver)
